SUTTNER ST-160 Single INJECTOR

Name: Suttner ST-160 Foam Injector
SKU: 521841

The Suttner ST-160 Chemical Injector is the most efficient and durable foam injector available, with a dilution range from 10:1 to 200:1. It automatically dilutes the soap to a predetermined strength eliminating soap waste or pre-mixing. The ST-160 arrives pre-set by us to draw at 100:1(1%) dilution, the ideal strength for all of our super concentrated liquids.

Includes

1. 3/8" Plug (Inlet)
2. Chemical Pick Up Tube Barb (Inlet)
3. 3/8" Coupler (Outlet)
4. 10' Clear Pick Up Tube
5. Chem-X Flow Cap
6. 10 Dosing Nozzles & O-Rings

Plug Play
Uses 4-5x Less Soap Than Traditional Style Injectors
9 Dosing Nozzles Included
Durable Stainless Steel Construction

HOW TO INSTALL

1. Connect ST-160 injector after power washer and before your high psi hose. The ST-160 will be made ready with a stainless 3/8" quick connect plug on the inlet and a stainless 3/8" quick connect socket on the the outlet.

2. Place chemical pick up tube directly into soap.

3. Foam all of the things!

Injector will be set to run at 100:1 unless specified otherwise, this can be changed by simply changing metering tip inside injector barb.
If using a hot water machine, scale build up from your coil can plug injector or foam head. On start up always run with injector in rinse mode for about 30-60 seconds to flush out any build up.
If a jumper hose is needed to go from your power washer to ST-160 injector please see our selection of hoses in accessories.
Other downstream injectors must be removed from your machine.
Limited to 150' of power washer hose after the injector.
ST-160 injectors come standard with a on the inlet and a on the outlet. QC orientation can be reversed upon request.

- -

*Other downstream injectors must be removed from your machine.
*Limited to 150' of power washer hose after the injector.
*ST-160 injectors come standard with a on the inlet and a on the outlet. QC orientation can be reversed upon request.
